attach-gateway

Attach Gateway

Identity & Memory side‑car for every LLM engine and multi‑agent framework. Add OIDC / DID SSO, A2A hand‑off, and a pluggable memory bus (Weaviate today) – all with one process.

Why it exists

LLM engines such as Ollama or vLLM ship with zero auth. Agent‑to‑agent protocols (Google A2A, MCP, OpenHands) assume a Bearer token is already present but don’t tell you how to issue or validate it. Teams end up wiring ad‑hoc reverse proxies, leaking ports, and copy‑pasting JWT code.

Attach Gateway is that missing resource‑server:

Run it next to any model server and get secure, shareable context in under 1 minute.

60‑second Quick‑start (local laptop)

# 0) prerequisites: Python 3.12, Ollama installed, Auth0 account or DID token

git clone https://github.com/attach-dev/attach-gateway.git && cd attach-gateway
python -m venv .venv && source .venv/bin/activate
pip install -r requirements.txt weaviate-client[embedded]

# 1) start embedded memory (background tab)
python script/start_weaviate.py &

# 2) export your short‑lived token
export JWT="<paste Auth0 or DID token>"
export OIDC_ISSUER=https://YOUR_DOMAIN.auth0.com
export OIDC_AUD=ollama-local
export MEM_BACKEND=weaviate
export WEAVIATE_URL=http://127.0.0.1:6666

# 3) run gateway
uvicorn main:app --port 8080 &

# 4) make a protected Ollama call via the gateway
curl -H "Authorization: Bearer $JWT" \
     -d '{"model":"tinyllama","prompt":"hello"}' \
     http://localhost:8080/api/chat | jq .

You should see a JSON response plus X‑ATTACH‑Session‑Id header – proof the pipeline works.

Architecture (planner → coder hand‑off)

flowchart TD
    %%────────────────────────────────
    %%  COMPONENTS
    %%────────────────────────────────
    subgraph Front-end
        UI["Browser<br/> demo.html"]
    end

    subgraph Gateway
        GW["Attach Gateway<br/> (OIDC SSO + A2A)"]
    end

    subgraph Agents
        PL["Planner Agent<br/>FastAPI :8100"]
        CD["Coder Agent<br/>FastAPI :8101"]
    end

    subgraph Memory
        WV["Weaviate (embedded)\nclass MemoryEvent"]
    end

    subgraph Engine
        OL["Ollama / vLLM<br/>:11434"]
    end

    %%────────────────────────────────
    %%  USER FLOW
    %%────────────────────────────────
    UI -- ① POST /a2a/tasks/send<br/>Bearer JWT, prompt --> GW

    %%─ Planner hop
    GW -- ② Proxy → planner<br/>(X-Attach-User, Session) --> PL
    PL -- ③ Write “plan” doc --> WV
    PL -- ④ /a2a/tasks/send\nbody:{mem_id} --> GW

    %%─ Coder hop
    GW -- ⑤ Proxy → coder --> CD
    CD -- ⑥ GET plan by mem_id --> WV
    CD -- ⑦ POST /api/chat\nprompt(plan) --> GW
    GW -- ⑧ Proxy → Ollama --> OL
    OL -- ⑨ JSON response --> GW
    GW -- ⑩ Write response to Weaviate --> WV
    GW -- ⑪ /a2a/tasks/status = done --> UI

Key headers

Header Meaning
Authorization: Bearer <JWT> OIDC or DID token proved by gateway
X‑Attach‑User stable user ID (auth0|123 or did:pkh:…)
X‑Attach‑Session deterministic hash (user + UA) for request trace

Live two‑agent demo (no Docker)

# pane 1 – memory
python script/start_weaviate.py

# pane 2 – gateway
uvicorn main:app --port 8080

# pane 3 – planner agent
uvicorn agents.planner:app --port 8100

# pane 4 – coder agent
uvicorn agents.coder:app   --port 8101

# pane 5 – static chat UI
cd examples/static && python -m http.server 9000
open http://localhost:9000/demo.html

Type a request like “Write Python to sort a list.” The browser shows:

  1. Planner message   → logged in gateway, plan row appears in memory.
  2. Coder reply       → code response, second memory row, status done.

Directory map

Path Purpose
auth/ OIDC & (soon) DID‑JWT verifiers
middleware/ JWT middleware, session header, mirror trigger
a2a/ /tasks/send & /tasks/status routes
mem/ pluggable memory writers (weaviate.py, null.py)
agents/ examples – Planner & Coder FastAPI services
examples/static/ demo.html chat page

Roadmap

License

MIT
